DG-M22-seat · 48 V · 4 kW
DG-M2 2-Seat Electric Golf Cart
Compact two-seater from the upgraded M series — nimble, refined and ready for tight fairways, resort paths and campus loops.
Seats
2
Dimensions
2400 × 1180 × 1870 mm
Curb Weight
520 kg
Max Load
360 kg
Speed
18–24 km/h
Gradeability
15%
Power
48 V · 4 kW
Range
60–120 km (by battery option)
Full Specifications
Overview
Model
DG-M2
Type
2-seat electric golf cart
Seating Capacity
2 persons
Intended Use
Golf courses, resorts, communities, campuses, airports, exhibitions
Dimensions & Weight
Overall Dimensions (L×W×H)
2400 × 1180 × 1870 mm
Curb Weight
520 kg
Max Load
360 kg
Performance
Max Speed
18–24 km/h
Gradeability
15%
Range
60–120 km depending on battery option
Drivetrain & Battery
System Voltage
48 V
Motor Power
4 kW
Battery
Deep-cycle lead-acid (standard); lithium upgrade available
Charging
Onboard intelligent charger
Chassis & Body
Chassis
Micro-car chassis structure; electrophoretic + baked paint double anti-corrosion
Body Panels
Injection-molded high-strength engineering plastic
Front Suspension
MacPherson independent suspension
Rear Suspension
Trailing-arm suspension
Brakes
Rear mechanical drum brakes + mechanical foot parking brake
Customization
Theme Colors
Custom color schemes available
Branding
LOGO printing and decal customization
Accessories
Windshield, canopy, club-holder racks on request
Specifications are subject to change without notice due to continuous product improvement. Confirm final parameters with our sales team for your order.
